3V blade for fire damper

The fire damper series of equipment mainly consists of: (I) the Frame production line; (II) the blade forming machine; (III) the backstay forming machine; (IV) the leaf spring forming machine; (V) the positive pressure air supply outlet production line; (VI) the positive pressure air supply outlet baffler production line; (VII) the riveting platform; and (VIII) the related complementary molds.




The fire damper series of equipment mainly consists of: (I) the Frame production line; (II) the blade forming machine; (III) the backstay forming machine; (IV) the leaf spring forming machine; (V) the positive pressure air supply outlet production line; (VI) the positive pressure air supply outlet baffler production line; (VII) the riveting platform; and (VIII) the related complementary molds.

Contact: * Company: MSN/skype: Subject: Tel: Fax: E-mail: * Website: Content: * Code: *(marked *should be filled)

3V Blade for Fire Damper, Fire damper blade

(II) Production Flow Processes and Main Features

Decoiling → Cold roll forming → Straightening, shaping → Cutting to length, punching → Manual discharge

(III) Components List

1. Two non-powered manual internally-braced feed racks

2. One set of main forming machine

3. One set of cutting, punching and notching molds

4. One set of electric control system

5. One set of hydraulic control system

A 3V blade is a reinforced, roll-formed steel blade design for fire dampers, featuring three longitudinal “V”-shaped grooves that boost rigidity, minimize deflection, and enhance sealing when closed. It is widely used in UL-listed fire/smoke dampers for reliable fire containment and airflow control.

Key Details

• Structure: Typically 16-gauge (≈1.5mm) galvanized or stainless steel, with three integral V - shaped ribs for structural reinforcement, preventing warping under high temperatures or airflow pressure.

• Function: When the damper closes (triggered by a fusible link), the 3V profile ensures tight blade - to - blade and blade - to - frame contact, reducing smoke/fire leakage and meeting UL 555 (fire) and UL 555S (smoke) leakage classes (often Class I/II).

• Performance: Suitable for dynamic (fan - on) and static (fan - off) applications, handling air velocities up to 2000–4000 fpm and pressures up to 4–10 in.w.g., with fire ratings of 1.5–3 hours.

• Design Benefits: The V - ribs improve strength without adding excessive weight, enabling efficient manufacturing and consistent performance across rectangular/square duct installations.
